Monel BSP / NPT Fittings

Home > Monel > Monel BSP / NPT Fittings

Ayten Tube Fittings, a leading manufacturer and supplier based in Addis Ababa, Ethiopia, offers high-quality Monel BSP / NPT Fittings designed for durability, corrosion resistance, and reliable performance in demanding industrial applications. Made from premium Monel alloys, these fittings ensure leak-proof connections and excellent mechanical strength under high pressure and temperature conditions. Known for their resistance to seawater, acids, and alkalis, Ayten’s Monel BSP / NPT Fittings are ideal for critical piping and instrumentation systems. Trusted across chemical, petrochemical, marine, oil and gas, and power generation industries, these fittings deliver long-term reliability and operational safety.

Monel Alloy 400 NPT Threaded Fittings Manufacturer Addis Ababa, ASTM B564 C276 Monel BSP Threaded Fittings Dealer Dire Dawa, Monel Alloy NPT Equal Cross Dealers Supplier Gondar, 400 Monel Alloy BSP 45 Deg Elbow Exporter In Adama, Monel Alloy Class 300 NPT 45° Elbow Mek’ele, ASME B16.11 Monel Alloy BSP Crosses Addis Ababa, Ethiopia.

Monel BSP / NPT Fittings are manufactured from Monel 400 or Monel K500 alloys, primarily composed of nickel (≈67%) and copper (≈30%), with minor additions of iron and manganese. Monel 400 provides excellent corrosion resistance, ductility, and toughness, while Monel K500 offers enhanced tensile and yield strength through age-hardening. These fittings maintain mechanical stability under high pressure, temperature variations, and corrosive environments. Their robust design ensures superior fatigue resistance and leak-free performance, making them ideal for aggressive fluids and high-stress industrial applications.

Monel BSP / NPT Fittings Specifications

Specifications: ASTM B564/ ASME SB564
Size: 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Types : Socketweld Fittings, Screwed-Threaded Fittings
Pressure Rating: Threaded End-2000lb/ 3000lb/ 6000lbs /
Socket-weld End-3000/ 6000/ 9000lbs
Thread: NPT, BSPT, BSPP

Monel BSP / NPT Fittings Chemical Composition

Grade	Ni	C	Al	Mn	Si	Fe	Cu	S
Monel BSP / NPT Fittings	63.0 min	0.3 max	0.50 max	2.0 max	0.5 max	1.0 – 2.5	28.0 – 34.0	0.02 max

Monel BSP / NPT Fittings Mechanical Properties

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.8 g/cm3	1350 °C (2460 °F)	Psi – 35,000 , MPa – 240	Psi – 80,000 , MPa – 550	40 %

Types of Monel BSP / NPT Fittings

Equivalent Grades of Monel BSP / NPT Fittings

STANDARD	WERKSTOFF NR.	UNS
Monel BSP 400	2.4360	N04400
Monel NPT K500	2.4375	N05500

ASME B16.11 Monel 400 NPT Barrel Nipple Price in Addis Ababa, 400 Monel Alloy BSP NPT Fittings Manufacturer Supplier in Dire Dawa, Monel Alloy BSP Reducing Bush Manufacturer in Gondar, Monel NPT Full Coupling Price in Adama, Nickel Alloy K500 BSP Hex Head Plug Supplier And Manufacturer in Mek’ele, ASTM B564 K500 Monel Alloy NPT Round Cap In Addis Ababa, Ethiopia.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Monel BSP / NPT Fittings in Addis Ababa, Ethiopia

At Ayten Tube Fittings, we are proud to be the largest supplier, manufacturer, and exporter of Monel BSP / NPT Fittings in Addis Ababa, Ethiopia. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Ethiopia, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Monel BSP / NPT Fittings Uses

Monel BSP / NPT Fittings are extensively used in industries that require secure, corrosion-resistant connections for fluid and gas systems. In the chemical and petrochemical industries, they are used for pipelines carrying acids, alkalis, and other corrosive fluids. The marine industry employs them in seawater, brine, and offshore systems due to their resistance to chloride attack. In oil and gas operations, they ensure reliable connections in high-pressure pipelines and instrumentation systems. Additionally, they are used in power generation, aerospace, and desalination plants, offering long-lasting performance, leak-free operation, and safety in demanding industrial environments.
