Ayten Tube Fittings is a reputable manufacturer and supplier of Hydraulic Weldable Nipples based in Addis Ababa, Ethiopia. They’re well-known for providing high-performance, leak-proof hydraulic components that are perfect for a variety of industrial systems. These weldable nipples are crafted with precision threads and robust materials to guarantee secure and dependable hydraulic connections. Built to endure high pressure, temperature, and vibration, Hydraulic Weldable Nipples deliver outstanding strength and resistance to corrosion. They’re an excellent choice for hydraulic systems, machinery, and process industries, ensuring easy installation, low maintenance, and optimal operational efficiency even in the toughest conditions.
Hydraulic Weldable Nipples are generally made from carbon steel, stainless steel, or alloy steel, with options for surface treatments like zinc plating or galvanizing to boost corrosion resistance. These nipples showcase impressive tensile strength (up to 600 MPa) and yield strength (around 350 MPa), ensuring they perform reliably under extreme pressure and temperature. They also excel in fatigue and vibration resistance, maintaining their structural integrity in dynamic hydraulic settings. The strong metallurgical composition ensures durability, ductility, and weldability, making them ideal for long-term, high-pressure fluid transfer applications.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| BODY TYPE | BAR STOCK |
| ACCESSORIES | O-RING |
| O-RING & SEALS | NBR ( -35*C TO 100* C ) VITON (-25*C TO 200* C) |
| SURFACE | CARBON STEEL – BLACK PHOSPHATED |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A. | |
| BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Weldable Nipple in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Outer Diameter (mm) | To Fit Tube Size (mm) | d1 (mm) | L (mm) | O-Ring (mm) | Max. Pressure (bar) |
| 8 | 8 x 2 | 4 | 31 | 6 x 1.5 | 400 |
| 10 | 10 x 1.5 | – | – | – | 400 |
| 10 | 10 x 2 | 6 | 32.5 | 7.5 x 1.5 | 315 |
| 12 | 12 x 2.5 | 6 | 32.5 | 9 x 1.5 | 400 |
| 16 | 16 x 2 | – | – | – | 400 |
| 16 | 16 x 3 | 10 | 38.5 | 12 x 2 | 400 |
| 20 | 20 x 3 | 14 | 44.5 | 16.3 x 2.4 | 250 |
| 25 | 25 x 3 | 19 | 49.5 | 20.3 x 2.4 | 250 |
| 25 | 25 x 4 | 17 | 49.5 | 20.3 x 2.4 | 315 |
| 30 | 30 x 4 | 22 | 52 | 25.3 x 2.4 | 250 |
| 30 | 30 x 5 | 20 | 52 | 25.3 x 2.4 | 315 |
| 38 | 38 x 4 | 30 | 56.5 | 33.3 x 2.4 | 160 |
| 38 | 38 x 5 | 28 | 56.5 | 33.3 x 2.4 | 250 |
| 38 | 38 x 6 | 26 | 56.5 | 33.3 x 2.4 | 315 |
Contact us to get a quick quote for your requirement.
Ayten Tube Fittings is a leading supplier and stockist of premium Hydraulic Weldable Nipple in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Hydraulic Weldable Nipples are essential components in hydraulic power systems, industrial machinery, agricultural equipment, and construction vehicles. They serve a crucial purpose by creating a robust, welded connection between pipes or hoses in systems that carry hydraulic fluids under pressure. These fittings are particularly well-suited for hydraulic cylinders, pumps, valves, and control systems, guaranteeing leak-free operation and a long lifespan. You’ll also find them in the oil and gas, marine, and manufacturing sectors, where durability and reliability are key. Thanks to their impressive mechanical strength and outstanding corrosion resistance, they’re ideal for both stationary and mobile hydraulic applications.
Please feel free to contact us if you need any further information or for enquiry.
