Home > Hydraulic Female Stud Coupling
Ayten Tube Fittings, a prominent manufacturer and supplier located in Addis Ababa, Ethiopia, focuses on crafting high-performance Hydraulic Female Stud Couplings that are built for reliability and durability in tough hydraulic systems. These couplings guarantee leak-proof and secure connections between hydraulic components, ensuring efficient fluid transfer even under high-pressure conditions. Made to comply with global quality standards, Ayten’s Hydraulic Female Stud Couplings are celebrated for their precision engineering, strength, and resistance to corrosion. The company proudly caters to various industries, including automotive, construction, agriculture, and manufacturing, providing reliable hydraulic solutions for a wide range of industrial applications.
Hydraulic Female Stud Couplings are generally constructed from top-quality carbon steel, stainless steel, or brass, incorporating alloying elements like chromium, nickel, and molybdenum to boost strength and corrosion resistance. They typically exhibit a tensile strength of around 500–700 MPa and a yield strength close to 340 MPa, ensuring excellent mechanical stability. With high ductility, precise dimensions, and resistance to vibrations, these couplings promise reliable sealing and a long service life, even when faced with extreme temperature and pressure fluctuations.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO FEMALE THREAD, WELD NIPPLE TO FEMALE THREAD |
| BODY TYPE | BAR STOCK |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A. | |
| BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Male Stud Coupling in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Tube O/D (mm) | Series | BSPP Female Thread | Pressure bar |
|---|---|---|---|
| 6 | L | G 1/8 | PN 315 |
| 6 | L | G 1/4 | PN 315 |
| 6 | L | G 3/8 | PN 315 |
| 8 | L | G 1/4 | PN 315 |
| 8 | L | G 3/8 | PN 315 |
| 8 | L | G 1/2 | PN 315 |
| 10 | L | G 1/4 | PN 315 |
| 10 | L | G 3/8 | PN 315 |
| 10 | L | G 1/2 | PN 315 |
| 12 | L | G 1/4 | PN 315 |
| 12 | L | G 3/8 | PN 315 |
| 12 | L | G 1/2 | PN 315 |
| 15 | L | G 3/8 | PN 315 |
| 15 | L | G 1/2 | PN 315 |
| 18 | L | G 1/2 | PN 315 |
| 22 | L | G 3/4 | PN 160 |
| 28 | L | G 1 | PN 160 |
| 35 | L | G 1 1/4 | PN 160 |
| 42 | L | G 1 1/2 | PN 160 |
| 6 | S | G 1/4 | PB 630 |
| 8 | S | G 1/4 | PB 630 |
| 10 | S | G 3/8 | PB 630 |
| 12 | S | G 3/8 | PB 630 |
| 12 | S | G 1/2 | PB 630 |
| 14 | S | G 1/2 | PB 630 |
| 16 | S | G 1/2 | PB 400 |
| 20 | S | G 3/4 | PB 400 |
| 25 | S | G 1 | PB 400 |
| 30 | S | G 1 1/4 | PB 400 |
| 38 | S | G 1 1/2 | PB 315 |
Contact us to get a quick quote for your requirement.
Ayten Tube Fittings is a leading supplier and stockist of premium Hydraulic Female Stud Coupling in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Hydraulic Female Stud Couplings find extensive use in hydraulic circuits, industrial machinery, automotive systems, construction equipment, and agricultural hydraulics. They are designed to securely connect hydraulic hoses and pipes to fittings or components, ensuring a steady fluid flow with minimal leakage. These couplings excel in hydraulic pumps, press machines, excavators, tractors, and material handling systems, where strength and sealing integrity are paramount. Their corrosion resistance, precise design, and durability make them perfect for high-pressure and high-performance hydraulic applications across various industries.
Please feel free to contact us if you need any further information or for enquiry.
