Ayten Tube Fittings is a well-respected manufacturer and supplier of precision-engineered hydraulic components located in Addis Ababa, Ethiopia. We focus on creating durable and high-performance **Hydraulic Equal Cross fittings**, which are designed to connect and evenly distribute fluid across four intersecting hydraulic lines. Our Equal Cross fittings are built to withstand high-pressure environments, featuring superior leak-proof sealing and precise dimensional accuracy. Crafted with advanced technology and top-quality materials, they guarantee strength, reliability, and resistance to corrosion. Ayten Tube Fittings proudly caters to industries like oil and gas, construction, automotive, agriculture, and manufacturing, offering efficient and long-lasting hydraulic connection solutions for a variety of applications.
Hydraulic Equal Cross fittings are generally made from **Carbon Steel, Stainless Steel (304/316), or Brass**, depending on the specific operational needs. These materials provide outstanding mechanical strength, corrosion resistance, and durability even in high-pressure and high-temperature situations. Carbon steel options deliver excellent load-bearing capacity, while stainless steel offers superior protection against rust and oxidation. Mechanically, these fittings showcase high tensile and yield strength, fatigue resistance, and structural stability. Their precise design ensures tight, leak-free connections and consistent performance, making them ideal for critical hydraulic circuits that face vibration, pressure surges, and demanding operating conditions.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| EQUIVALENT BRANDS | PARKER, HY-LOK , DK-LOK , STAUFF, HYDAC , VOSS |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Equal Cross in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Thread | CH | L1 | L2 | T1 | Pressure PN | Weight kg 100pcs | Series |
|---|---|---|---|---|---|---|---|
| Thread F1 | mm | mm | mm | mm | bar | ||
| 12×1,5 | 12 | 12 | 27 | 6 | 315 | 7,8 | L |
| 12×1,5 | 12 | 12 | 27 | 6 | 315 | 7,8 | L |
| 14×1,5 | 12 | 14 | 29 | 8 | 315 | 11,0 | L |
| 14×1,5 | 12 | 14 | 29 | 8 | 315 | 11,0 | L |
| 16×1,5 | 14 | 15 | 30 | 10 | 315 | 15,7 | L |
| 16×1,5 | 14 | 15 | 30 | 10 | 315 | 15,7 | L |
| 18×1,5 | 17 | 17 | 32 | 12 | 315 | 19,5 | L |
| 18×1,5 | 17 | 17 | 32 | 12 | 315 | 19,5 | L |
| 22×1,5 | 19 | 21 | 36 | 15 | 315 | 31,5 | L |
| 22×1,5 | 19 | 21 | 36 | 15 | 315 | 31,5 | L |
| 26×1,5 | 24 | 23,5 | 40 | 18 | 315 | 48,7 | L |
| 26×1,5 | 24 | 23,5 | 40 | 18 | 315 | 48,7 | L |
| 30×2 | 27 | 27,5 | 44 | 22 | 160 | 73,0 | L |
| 30×2 | 27 | 27,5 | 44 | 22 | 160 | 73,0 | L |
| 36×2 | 36 | 30,5 | 47 | 28 | 160 | 101,5 | L |
| 36×2 | 36 | 30,5 | 47 | 28 | 160 | 101,5 | L |
| 45×2 | 41 | 34,5 | 56 | 35 | 160 | 123,5 | L |
| 45×2 | 41 | 34,5 | 56 | 35 | 160 | 123,5 | L |
| 52×2 | 50 | 40 | 63 | 42 | 160 | 176,5 | L |
| 52×2 | 50 | 40 | 63 | 42 | 160 | 176,5 | L |
| 14×1,5 | 12 | 16 | 31 | 6 | 630 | 13,0 | S |
| 14×1,5 | 12 | 16 | 31 | 6 | 630 | 13,0 | S |
| 16×1,5 | 14 | 17 | 32 | 8 | 630 | 17,0 | S |
| 16×1,5 | 14 | 17 | 32 | 8 | 630 | 17,0 | S |
| 18×1,5 | 17 | 17,5 | 34 | 10 | 630 | 24,2 | S |
| 18×1,5 | 17 | 17,5 | 34 | 10 | 630 | 24,2 | S |
| 20×1,5 | 17 | 21,5 | 38 | 12 | 630 | 30,1 | S |
| 20×1,5 | 17 | 21,5 | 38 | 12 | 630 | 30,1 | S |
| 22×1,5 | 19 | 22 | 40 | 14 | 630 | 39,0 | S |
| 22×1,5 | 19 | 22 | 40 | 14 | 630 | 39,0 | S |
| 24×1,5 | 24 | 24,5 | 43 | 16 | 400 | 49,0 | S |
| 24×1,5 | 24 | 24,5 | 43 | 16 | 400 | 49,0 | S |
| 30×2 | 27 | 26,5 | 48 | 20 | 400 | 76,0 | S |
| 30×2 | 27 | 26,5 | 48 | 20 | 400 | 76,0 | S |
| 36×2 | 36 | 30 | 54 | 25 | 400 | 138,0 | S |
| 36×2 | 36 | 30 | 54 | 25 | 400 | 138,0 | S |
| 42×2 | 41 | 35,5 | 62 | 30 | 400 | 172,0 | S |
| 42×2 | 41 | 35,5 | 62 | 30 | 400 | 172,0 | S |
| 52×2 | 50 | 41 | 72 | 38 | 315 | 269,0 | S |
| 52×2 | 50 | 41 | 72 | 38 | 315 | 269,0 | S |
Contact us to get a quick quote for your requirement.
Ayten Tube Fittings is a leading supplier and stockist of premium Hydraulic Equal Cross in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Hydraulic Equal Cross fittings are extensively utilized in **hydraulic and pneumatic systems** to connect four pipes or tubes of equal diameter, facilitating smooth and balanced fluid distribution. They find common use in **construction machinery, agricultural equipment, industrial hydraulics, and mobile hydraulic systems**. In the **oil and gas, marine, and power generation sectors**, these fittings play a crucial role in ensuring efficient fluid transfer and system reliability. Their versatility and robust design make them essential components in various applications, where dependable performance is key to operational success.
